How do I connect my Xbox one to my Wi-Fi


How do I connect my Xbox one to my Wi-Fi ?

Here’s how you do that

You can change the way you connect to the Internet at any time during your use of the Xbox One. For example, if you are moving to a new place, you may want to use a different wireless network than the one you have used in the past. Here’s how you do that:

1.   Turn on your Xbox One and go to the Settings menu.

2.   Select Network.

3.   Select Set Up wireless network, to connect to a new network.

4.   Xbox One asks Which one is yours? and displays the wireless networks it detects in your area.

5.   Select the network you want to connect to.

6.   Type the password used by that wireless network using the keyboard displayed on the screen.

7.   Press the Enter button on your controller.

8.   Xbox One connects to the network you select, using the password you provided.
Then, it checks whether it can connect to the Internet. If all is well, Xbox One informs you that your console is now connected to the Internet.

9.   Press Continue to get back to the Network Settings.
10.Press the Home button on your controller.

You are now connected to the new wireless network you have selected.


This is the simplest method for connecting the Xbox One to your home network. You need a network cable and your router, which is set up to connect to the Internet and provide network access to the devices you are using.

قد يهمك أيضاً الأطلاع على:  Mobile Ultimate Guide

Plug it in the Ethernet network port, on the back side of your Xbox One. Then, plug the other end of the cable in one of the available Ethernet ports, on the back of your router. The Xbox One will detect the wired connection and configure itself appropriately. There’s no manual configuration to perform.

Most routers are configured to assign IP addresses automatically to all the devices that are connected to your network and automatically provide Internet access to them. If your router doesn’t automatically give IP addresses to all the devices that are connected to your network, please consult your router’s manual to figure out how to set it up. Otherwise, your Xbox One won’t receive an IP address and Internet access. This procedure varies from router to router so we can’t help with providing step by step instructions how to do this.


If you are having trouble joining online games on your Xbox 360, or if you can’t hear other players in games you’ve joined, you may have a Network Address Translation problem.

The NAT on an Xbox 360 is set to open, moderate, or strict. The latter two NATs limit the connections that your Xbox 360 can make with other consoles on the network: Moderate NATs can connect only with consoles using moderate and open NATs, and strict NATs can connect only with consoles using open NATs. The bottom line is that you want an open NAT setting in order to connect with other players smoothly.

Is It a NAT Problem ?

First, find out if your connection problem is a NAT issue.

  1. On your Xbox 360, open My Xbox.
  2. Choose System Settings.
  3. Choose Network Settings.
  4. Choose Wired Networkor your wireless network name.
  5. Choose Test Xbox LIVE Connection.

If you have a NAT problem, you’ll see a yellow exclamation point and text reading ‘Your NAT type is set to [Strict or Moderate].’

Opening the NAT Settings

First, you need to gather some information about your network:

  1. On a PC connected to your network, click Start,and then type cmd into the search field. Press Enter.
  2. In the window that pops up, type ipconfigand press Enter.
  3. Look under the heading for your network connection–which you’ll likely find listed as Local Area Connection or Wireless Network Connection–and record the numbers given for the following items:
  • IPv4 Address (or IP Address)
  • Subnet Mask
  • Default Gateway

Second, you need to turn on Universal Plug and Play for your router.

  1. On a PC connected to your network, open a Web browser.
  2. Type the Default Gateway number (that you recorded earlier) into the address bar, and press Enter.
  3. Type in the username and password for your router. Username and password defaults vary based on the router model. If you are unsure of your default username and password, refer to your router’s documentation or find them using the guide on the Port Forward website. If someone changed the default login information and you don’t know it, you’ll need to reset your router.
  1. Make sure that UPnP is turned on. Refer to your router’s documentation if you can’t find the UPnP setting.
  2. Restart your Xbox 360, and run the connection test again.

If your router doesn’t have UPnP, or if turning UPnP on doesn’t open your NAT, you need to assign a static IP address to your Xbox 360 and set up port forwarding.

  1. In the Network Settings menu on your Xbox 360, select the Basic Settings tab.
  2. Choose Manual.
  3. Select IP Address.
  4. Take the Default Gateway number that you recorded earlier, and add 10 to the last number. For example, if your Default Gateway is, the new number is This new number is your static IP address; enter it as the IP address, and then choose Done.
  5. Select Subnet Mask, enter the Subnet Mask number that you recorded earlier, and then choose Done.
  6. Choose Gateway, enter the Default Gateway number that you recorded earlier, and then choose Done.
  7. Select Done again.
  8. On a PC connected to your network, open a Web browser and log in to your router’s interface.
  9. Open the following ports:
  • Port 88 (UDP)
  • Port 3074 (UDP and TCP)
  • Port 53 (UDP and TCP)
  • Port 80 (TCP)
قد يهمك أيضاً الأطلاع على:  أسهل طريقة لتحويل ملف Word إلى PDF مجانًا

If you aren’t sure how to open ports on your router, refer to your router’s documentation or to the guide on the Port Forward website.

Still No Luck ?

If you’ve performed all of the steps above, and the connection test still reports a aseconds, and then turn on your router. Wait 60 more seconds, and then turn on your Xbox 360 and test again.

You can also try entering the static IP address you created earlier into the DMZ field in your router’s settings. Log in to your router’s interface, search for DMZ Host, type in the static IP, and then apply the changes.

  • we can also  add dns on cpe page or change wifi password & ssid name & try to connect again

    Note:  When you set up your Xbox One console for the first time, you are asked whether you would like to connect to the network. You can go ahead and set the network connection during the initial setup or later. Here’s how to connect your Xbox One to the network and the Internet, using both wired and wireless connections.
